Capacity and Dimensions

• Sheet length
  mm 2300
• Maximum material length
  mm 2300
• Maximum material width
  mm 1500
• Maximum bend height/depth
  mm 254
• Minimum bending size (4 sides)
  mm 410 x 410
• Minimum bending size (1 side)
  mm 210
• Minimum bending radius
  mm 1.2
• Twisting speed
  Seconds 0.5
• Pressure clearance
  mm 265
• Maximum bending angle
  +/- 145°
• Minimum bending diameter
  mm Steel: 1.5
• Minimum bending diameter
  mm Stainless steel: 1
• Minimum bending diameter
  mm Aluminum: 2
• Software
  ERFOLD
• Number of axis
  Servo 11
• Machine dimensions
  Length mm 5000
• Machine dimensions
  Width mm 3915
• Machine dimensions
  Height mm 2850
• Machine weight
  kg 15000
